139
Drain Installation B-30 Prewash RL
1 100110WELD-STUD,1/4-20 X 3/4 LG.SST 1
2 100141 HEX GRIP NUT,1/4-20 SST,CTR LOCK1
3 100154 HEX PLAIN NUT,5/16-18 SST2
4 100161 ELBOW,2"NPT X 90,GALVANIZED1
5 100735 HEX HEAD,1/4-20 X 5/8 SST1
6 100739 HEX HEAD,5/16-18 X 3/4 SST6
7 100740 HEX HEAD,5/16-18 X 1 SST4
8 101939 NIPPLE,TOE,2"NPT X 11" LG.,GALV 1
9 101944 NIPPLE,2"NPT X 12 1/2" LG.,GALV 1
10 102376 WASHER,FLAT,5/16x3/4x.06 SST4
11 106013 WASHER,LOCK,5/16 SPLIT,SST2
12 106026 WASHER,FLAT,1/4x5/8x.06 SST6
13 107967 HEX GRIP NUT,1/4-20 SST W/NYLON1
14 108345 GASKET,HEATER/STANDPIPE2
15 114185 GRIP,DRAIN HANDLE1
16 304816 STRAINER,DRAIN 1
17 305840 OVERFLOW WELDMENT, 9.50 UC1
18 310259 BRACKET, DRAIN LINE SUPPORT,UC'S2
19 329677 SUPPORT BRACKET,DRAIN HANDLE1
20 601819 DRAIN SUB-ASSY, PW,2" TRUNK EUCCW 1
--- 601838 DRAIN SUB-ASSY, PW,2" TRUNK EUCC 1
