Champion Eseries - Page 153

145
Drain Installation Auxiliary LR
1 100110 WELD-STUD,1/4-20 X 3/4 LG.SST 1
2 100141 HEX GRIP NUT,1/4-20 SST,CTR LOCK 1
3 100154 HEX PLAIN NUT,5/16-18 SST 4
4 100735
HEX HEAD,1/4-20 X 5/8 SST 1
5 100736
HEX HEAD,1/4-20 X 3/4 SST 4
6 100739
HEX HEAD,5/16-18 X 3/4 SST 4
7 102376WASHER,FLAT,5/16x3/4x.06 SST 4
8 104165 CLAMP,HOSE,M40,52/76,SST GEAR TYPE 2
9 106013 WASHER,LOCK,5/16 SPLIT,SST 4
10 106026 WASHER,FLAT,1/4x5/8x.06 SST 2
11 107967 HEX GRIP NUT,1/4-20 SST W/NYLON 1
12 108345 GASKET,HEATER/STANDPIPE 1
13 111903 NIPPLE,TOE,2"NPT X 2" LG.,GALV1
14 114106 NIPPLE,TOE,2"NPT X 18" LG.,GALV1
15 114185 GRIP,DRAIN HANDLE 1
16 202073 HOSE,2.375 ID X 6.000 LG.EPDM 1
17 304816 STRAINER,DRAIN 1
18 310259 BRACKET, DRAIN LINE SUPPORT,UC'S 2
19 329130 GUARD, DRAIN VALVE 1
20 329677 SUPPORT BRACKET,DRAIN HANDLE 1
21 601821 DRAIN SUB-ASSY,ECO-RINSE, 2" TRUNK EUCCW 1
--- 601840 DRAIN SUB-ASSY,ECO-RINSE, 2" TRUNK EUCC 1
