151
Drain Installation B4 Prewash RL
1 100110 WELD-STUD,1/4-20 X 3/4 LG.SST 1
2 100141 HEX GRIP NUT,1/4-20 SST,CTR LOCK 1
3 100154 HEX PLAIN NUT,5/16-18 SST 2
4 100161 ELBOW,2"NPT X 90,GALVANIZED 1
5 100735
HEX HEAD,1/4-20 X 5/8 SST 1
6 100739
HEX HEAD,5/16-18 X 3/4 SST 6
7 100740
HEX HEAD,5/16-18 X 1 SST 4
8 102376 WASHER,FLAT,5/16x3/4x.06 SST 4
9 106013 WASHER,LOCK,5/16 SPLIT,SST 2
10 106026 WASHER,FLAT,1/4x5/8x.06 SST 6
11 106631 NIPPLE,TOE,2"NPT X 12 3/4" LG.,GALV1
12 107967 HEX GRIP NUT,1/4-20 SST W/NYLON 1
13 108345 GASKET,HEATER/STANDPIPE 2
14 114185 GRIP,DRAIN HANDLE 1
15 114252 NIPPLE,2"NPT X 29 1/2" LG.,GALV1
16 304816 STRAINER,DRAIN 1
17 305840 OVERFLOW WELDMENT, 9.50 UC 1
18 310259 BRACKET, DRAIN LINE SUPPORT,UC'S 2
19 329677 SUPPORT BRACKET,DRAIN HANDLE 1
20 601819 DRAIN SUB-ASSY,PW,2" TRUNK EUCCW 1
--- 601838 DRAIN SUB-ASSY,PW,2" TRUNK EUCC 1
