Champion Eseries - Page 189

181
R-L
L-R
Curtain Installation B4/C4 RL/LR
1 100734 8
2 106026 WASHER,FLAT,1/4x5/8x.06 SST8
3 106482 WASHER,LOCK,1/4 SPLIT,SST8
4112445CURTAIN,SHORT,14 X 32,NUCCW3
5114111CURTAIN,LONG,19 X 34 1/4,EUCCW2
6 204949 CURTAIN,SHORT,10 X 32,NUCCW AUX. RINSE 1
7 205432 ROD,CURTAIN,5/16 X 32"LG.SST,UCCW2
8 206581 ROD,CURTAIN,5/16 X 34 1/4"LG.SST,UCCW4
9 329719-2 BAFFLE, CURTAIN HANGER.MANIFOLD MTD,LH1
10 329720-2 BAFFLE, CURTAIN HANGER,HOOD MTD,RH2
11 330497 BAFFLE, CURTAIN ,BLANK,HOOD MTD1
12 331200-1 BAFFLE, CURTAIN HANGER,AUX. RINSE CENTER,R-L 1
HEX HEAD, 1/4-20 X 1/2 SST
1 100734 8
2 106026 WASHER,FLAT,1/4x5/8x.06 SST8
3 106482 WASHER,LOCK,1/4 SPLIT,SST8
4112445CURTAIN,SHORT,14 X 32,NUCCW3
5114111CURTAIN,LONG,19 X 34 1/4,EUCCW2
6 204949 CURTAIN,SHORT,10 X 32,NUCCW AUX. RINSE 1
7 205432 ROD,CURTAIN,5/16 X 32"LG.SST,UCCW2
8 206581 ROD,CURTAIN,5/16 X 34 1/4"LG.SST,UCCW4
9 329719-2 BAFFLE, CURTAIN HANGER.MANIFOLD MTD,LH1
10 329720-2 BAFFLE, CURTAIN HANGER,HOOD MTD,RH2
11 330497 BAFFLE, CURTAIN ,BLANK,HOOD MTD1
12 331200-1 BAFFLE, CURTAIN HANGER,AUX. RINSE CENTER,R-L 1
HEX HEAD, 1/4-20 X 1/2 SST
