183
Curtain Installation B4/C6 RL/LR
R-L
L-R
1 100734 14
2 106026 WASHER,FLAT,1/4x5/8x.06 SST14
3 106482 WASHER,LOCK,1/4 SPLIT,SST14
4112445CURTAIN,SHORT,14 X 32,NUCCW6
5114111CURTAIN,LONG,19 X 34 1/4,EUCCW2
6 204949 CURTAIN,SHORT,10 X 32,NUCCW E2 1
7 205432 ROD,CURTAIN,5/16 X 32"LG.SST,UCCW2
8 206581 ROD,CURTAIN,5/16 X 34 1/4"LG.SST,UCCW7
9 329719-2 BAFFLE, CURTAIN HANGER.MANIFOLD MTD,LH1
10 329720-1 BAFFLE, CURTAIN HANGER,HOOD MTD,LH2
11 329720-2 BAFFLE, CURTAIN HANGER,HOOD MTD,RH3
12 331200-1 BAFFLE, CURTAIN HANGER,AUX. RINSE CENTER,R-L 1
HEX HEAD, 1/4-20 X 1/2 SST
1 100734 16
2 106026 WASHER,FLAT,1/4x5/8x.06 SST16
3 106482 WASHER,LOCK,1/4 SPLIT,SST16
4112445CURTAIN,SHORT,14 X 32,NUCCW7
5114111CURTAIN,LONG,19 X 34 1/4,EUCCW2
6 204949 CURTAIN,SHORT,10 X 32,NUCCW AUX. RINSE 1
7 205432 ROD,CURTAIN,5/16 X 32"LG.SST,UCCW3
8 206581 ROD,CURTAIN,5/16 X 34 1/4"LG.SST,UCCW7
9 329719-1 BAFFLE, CURTAIN HANGER.MANIFOLD MTD,RH2
10 329720-1 BAFFLE, CURTAIN HANGER,HOOD MTD,LH3
11 329720-2 BAFFLE, CURTAIN HANGER,HOOD MTD,RH2
12 330223 HOOD WELDMENT,C3R-B,ELEC/STEAM1
13 331200-2 BAFFLE, CURTAIN HANGER,AUX. RINSE CENTER,L-R 1
HEX HEAD, 1/4-20 X 1/2 SST
