Champion Eseries - Page 193

185
Curtain Installation B30/C6 RL/LR
1 100734 CAP SCREW,HEX HEAD,1/4-20 X 1/2 SST16
2 106026 WASHER,FLAT,1/4x5/8x.06 SST16
3 106482 WASHER,LOCK,1/4 SPLIT,SST16
4112445CURTAIN,SHORT,14 X 32,NUCCW6
5114110CURTAIN,SHORT,14 X 34 1/4,EUCCW1
6114111 CURTAIN,LONG,19 X 34 1/4,EUCCW2
7 204949 CURTAIN,SHORT,10 X 32,NUCCW E2 1
8 205432 ROD,CURTAIN,5/16 X 32"LG.SST,UCCW3
9 206581 ROD,CURTAIN,5/16 X 34 1/4"LG.SST,UCCW7
10 329719-2 BAFFLE, CURTAIN HANGER.MANIFOLD MTD,LH 2
11 329720-1 BAFFLE, CURTAIN HANGER,HOOD MTD,LH2
12 329720-2 BAFFLE, CURTAIN HANGER,HOOD MTD,RH3
13 331200-1 BAFFLE, CURTAIN HANGER,E2 CENTER,R-L1
R-L
L-R
1 100734 16
2 106026 WASHER,FLAT,1/4x5/8x.06 SS
T1
6
3 106482 WASHER,LOCK,1/4 SPLIT,SS
T1
6
4112445 CURTAIN,SHORT,14 X 32,NUCC
W7
5114111 CURTAIN,LONG,19 X 34 1/4,EUCC
W2
6 204949 CURTAIN,SHORT,10 X 32,NUCCW AUX. RINSE 1
7 205432 ROD,CURTAIN,5/16 X 32"LG.SST,UCC
W3
8 206581 ROD,CURTAIN,5/16 X 34 1/4"LG.SST,UCC
W7
9 329719-1 BAFFLE, CURTAIN HANGER.MANIFOLD MTD,R
H2
10 329720-1 BAFFLE, CURTAIN HANGER,HOOD MTD,L
H3
11 329720-2 BAFFLE, CURTAIN HANGER,HOOD MTD,R
H2
12 331200-2 BAFFLE, CURTAIN HANGER, AUX. RINSE CENTER,L-R 1
HEX HEAD, 1/4-20 X 1/2 SST
