Supply Connections
Chemical dispensing systems are supplied by others.
A connection point for detergent, and rinse-aid signals is provided in the
in the top-mounted control cabinet.
SIGNAL ONLY
VENT FAN
COMMON
COMMON
120V
DETERGENT
120V
RINSE AID
120V
Installation Instructions
Supply Connections - Chemical Dispensers
