Champion Eseries - Page 73

65
1HP 30" Prewash Right-Left Wash System Installation
1 100734 HEX HEAD,1/4-20 X 1/2 SST14
2
100755 SCREW,FLAT HEAD,1/4-20 X 1/2 SST4
3
104414 O-RING,1 X 1 1/4 X 1/8 5
4
106014 HEX ACORN PLAIN NUT,1/4-20 SST4
5
106026 WASHER,FLAT,1/4x5/8x.06 SST15
6
106482 WASHER,LOCK,1/4 SPLIT,SST14
7
108875 COTTER PIN,3/32 X 1/2 UNEVEN 1
8
110858 HOSE CLAMP,HIGH PRESSURE,02561
9
111780 HOSE CLAMP,HIGH PRESSURE,02382
10
111964 HOSE CLAMP,HIGH PRESSURE,02751
11
112240 PLUG, DEBOSSED SPRAYPIPE5
12
113911 LOCKNUT,2 1/2" , NPSL, SST2
13
113912RETAINING RING, INTERNAL, 2" BORE2
14
113984 HOSE, DISCHARGE MOLDED E1
15
114096 O-RING,2.225x.210 DIA. 2
16
202146 HOSE,1.875 ID X 5.375 LG.EPDM 1
17
206553 ROD, LATCH PIVOT,3 HOLE MANIFOLD1
18
329669 TRACK WELDMENT, LH LOWER, MANIFOLD EUCCW 1
19
329670 TRACK WELDMENT, RH LOWER, MANIFOLD EUCCW 1
20
329672 TRACK WELDMENT, LH UPPER, MANIFOLD EUCCW 1
21
329673 TRACK WELDMENT, RH UPPER, MANIFOLD EUCCW 1
22
329674 BRACKET, LOWER MANIFOLD LATCH2
23
329696 MANIFOLD WELDMENT,3 HOLE,UPPER EUCCW 1
24
329699 MANIFOLD WELDMENT,2 HOLE,LOWER EUCCW 1
---
330644 TRACK WELDMENT, LH LOWER, MANIFOLD EUCC 1
---
330645 TRACK WELDMENT, RH LOWER, MANIFOLD EUCC 1
---
330641 TRACK WELDMENT, LH UPPER, MANIFOLD EUCC 1
---
330642 TRACK WELDMENT, RH UPPER, MANIFOLD EUCC 1
---
330637 MANIFOLD WELDMENT,3 HOLE,UPPER EUCC 1
---
330638 MANIFOLD WELDMENT,2 HOLE,LOWER EUCC 1
25
329705 LATCH DEVP, UPPER MANIFOLD,3 HOLE1
26
330308 MANIFOLD RESTRICTOR, 0.781" ID 1
27
330309 MANIFOLD RESTRICTOR, 0.531" ID 1
28
330698 STANDPIPE WELDMENT,B-30 RL 1
29
330838 TUBE, PUMP DISCHARGE, WELDMENT EUCCW1
30
114692 GASKET, STANDPIPE 2
--- 330679 TUBE, PUMP DISCHARGE, WELDMENT EUCC 1
