Champion Eseries - Page 75

67
1HP 30" Prewash Left-Right Wash System Installation
1 100734 CAP SCREW,HEX HEAD,1/4-20 X 1/2 SST14
2 100755 SCREW,FLAT HEAD,1/4-20 X 1/2 SST4
3 104414 O-RING,1 X 1 1/4 X 1/8 5
4 106014 HEX ACORN PLAIN NUT,1/4-20 SST4
5 106026 WASHER,FLAT,1/4x5/8x.06 SST15
6 106482 WASHER,LOCK,1/4 SPLIT,SST 14
7 108875 COTTER PIN,3/32 X 1/2 UNEVEN 1
8110858 HOSE CLAMP,HIGH PRESSURE,02561
9 111780 HOSE CLAMP,HIGH PRESSURE,02382
10 111964 HOSE CLAMP,HIGH PRESSURE,02751
11 112240 PLUG, DEBOSSED SPRAYPIPE 5
12 113911 LOCKNUT,2 1/2" , NPSL, SST2
13 113912RETAINING RING, INTERNAL, 2" BORE2
14 113984 HOSE, DISCHARGE MOLDED E1
15 114096 O-RING,2.225x.210 DIA. 2
16 202146 HOSE,1.875 ID X 5.375 LG.EPDM 1
17 206553 ROD, LATCH PIVOT,3 HOLE MANIFOLD1
18 329669 TRACK WELDMENT, LH LOWER, MANIFOLD EUCCW 1
19 330642 TRACK WELDMENT, RH LOWER, MANIFOLD EUCCW 1
20 329672 TRACK WELDMENT, LH UPPER, MANIFOLD EUCCW 1
21 329673 TRACK WELDMENT, RH UPPER, MANIFOLD EUCCW 1
22 329674 BRACKET, LOWER MANIFOLD LATCH2
23 329696 MANIFOLD WELDMENT,3 HOLE,UPPER EUCCW 1
24 329699 MANIFOLD WELDMENT,2 HOLE,LOWER EUCCW 1
25 329705 LATCH DEVP, UPPER MANIFOLD,3 HOLE1
26 330308 MANIFOLD RESTRICTOR, 0.781" ID 1
27 330309 MANIFOLD RESTRICTOR, 0.531" ID 1
28 330699 STANDPIPE WELDMENT,B-30 LR 1
29
30 114692 GASKET, STANDPIPE 2
330838 TUBE, PUMP DISCHARGE, WELDMENT EUCCW1
--- 329669 TRACK WELDMENT, LH LOWER, MANIFOLD EUCC 1
--- 329670 TRACK WELDMENT, RH LOWER, MANIFOLD EUCC 1
--- 330645 TRACK WELDMENT, LH UPPER, MANIFOLD EUCC 1
--- 330641 TRACK WELDMENT, RH UPPER, MANIFOLD EUCC 1
--- 330637 MANIFOLD WELDMENT,3 HOLE,UPPER EUCC 1
---
---
330638 MANIFOLD WELDMENT,2 HOLE,LOWER EUCC 1
330639 TUBE, PUMP DISCHARGE, WELDMENT EUCC1
