C4 Single Tank Wash System Installation
1 100734 HEX HEAD,1/4-20 X 1/2 SST14
2 100755 SCREW,FLAT HEAD,1/4-20 X 1/2 SST4
3 104414 O-RING,1 X 1 1/4 X 1/8 10
4 106014 HEX ACORN PLAIN NUT,1/4-20 SST4
5 106026 WASHER,FLAT,1/4x5/8x.06 SST15
6 106482 WASHER,LOCK,1/4 SPLIT,SST14
7 108875 COTTER PIN,3/32 X 1/2 UNEVEN 1
8110858 HOSE CLAMP,HIGH PRESSURE,02561
9 111780 HOSE CLAMP,HIGH PRESSURE,02382
10 111964 HOSE CLAMP,HIGH PRESSURE,02751
11 112240 PLUG, DEBOSSED SPRAYPIPE10
12 113911 LOCKNUT,2 1/2" , NPSL, SST2
13 113912RETAINING RING, INTERNAL, 2" BORE1
14 113984 HOSE, DISCHARGE MOLDED E1
15 114096 O-RING,2.225x.210 DIA. 2
16 202146 HOSE,1.875 ID X 5.375 LG.EPDM 1
17 206552 ROD, LATCH PIVOT,5 HOLE MANIFOLD1
18 329659 MANIFOLD WELDMENT,5 HOLE,UPPER EUCCW 1
19 329669 TRACK WELDMENT, LH LOWER, MANIFOLD EUCCW 1
20 329670 TRACK WELDMENT, RH LOWER, MANIFOLD EUCCW 1
21 329672 TRACK WELDMENT, LH UPPER, MANIFOLD EUCCW 1
22 329673 TRACK WELDMENT, RH UPPER, MANIFOLD EUCCW 1
--- 329659 MANIFOLD WELDMENT,5 HOLE,UPPER EUCC 1
--- 330632 TRACK WELDMENT, LH LOWER, MANIFOLD EUCC 1
--- 330644 TRACK WELDMENT, RH LOWER, MANIFOLD EUCC 1
--- 330641 TRACK WELDMENT, LH UPPER, MANIFOLD EUCC 1
--- 330642 TRACK WELDMENT, RH UPPER, MANIFOLD EUCC 1
23 329674 BRACKET, LOWER MANIFOLD LATCH2
24 329704 LATCH DEVP, UPPER MANIFOLD,5 HOLE1
25 330467 MANIFOLD WELDMENT,5 HOLE,LOWER- EUCCW 1
--- 330467 MANIFOLD WELDMENT,5 HOLE,LOWER- EUCC 1
26 330468 MANIFOLD RESTRIC
T
OR, 1.188" ID 1
27 330680 STANDPIPE WELDMEN
T
, C4 1
28
29 114692 GASKET, STANDPIPE
330838 TUBE, PUMP DISCHARGE, WELDMEN
T
EUCCW1
--- 330838 TUBE, PUMP DISCHARGE, WELDMENT EUCC1
2
