C4 Wash without Scrap Basket Electric Tank Heat Installation
1 100007 SCREW,TRUSS HEAD,10-32 x 3/8 SST3
2 100109 WELD-STUD,1/4-20 X 1/2 LG.SST 2
3 100154 HEX PLAIN NUT,5/16-18 SST12
4 100198 WELD-STUD,10-32 X 1/2 LG.SST 4
5 100547 LOCKNUT,1/2" NPT,SST2
6 100740 CAP SCREW,HEX HEAD,5/16-18 X 1 SST12
7 102376 WASHER,FLAT,5/16x3/4x.06 SST24
8 106013 WASHER,LOCK,5/16 SPLIT,SST 12
9 106026 WASHER,FLAT,1/4x5/8x.06 SST2
10 106486 WASHER,LOCK,#10 SPLIT,SST4
11 107033 WASHER,FLAT,.208X.438X.047 SST4
12 107136 SCREW,HEX HEAD,10-32 x 3/8 SST4
13 107839 TANK HEATER,RICA 5KW 208V/3ph 1
13 107842 TANK HEATER,RICA 5KW 480V/3ph 1
13 111123 TANK HEATER,RICA 5KW 575V/3ph
V/3ph
V/3ph
V/3ph
V/3ph
1
13 107840 TANK HEATER,RICA 5KW 240V/3ph 1
14 107951 TANK HEATER,RICA 10KW 208
14 107844 TANK HE
A
TER,RICA 10KW 240
14 107846
T
ANK HE
A
A
TER,RICA 10KW 480
14 111120 TANK HE TER,RICA 10KW 575
2
2
2
2
15 107966 HEX GRIP NUT,10-32 SST W/NYLON4
16 107967 HEX GRIP NUT,1/4-20 SST W/NYLON2
17 108345 GASKET,HEATER/STANDPIPE3
18 109069 THERMOSTAT,CONTROL,WITH CAPILLARY 1
19 110561 THERMOSTAT,HI-LIMIT,WITH CAPILLARY1
20 201041 WASHER,SPACER,7/8x1 3/16x1/8 NP 2
21 323430 BRACKET, THERMOSTATS,USN72,44CR1
22 329768 COVER,HEATER BOX,C4-BKT1
23 329769 HEATER BOX WELDMENT,C4-B1
