Champion Eseries - Page 97

89
Electric Booster Installation
1 100003 HEX PLAIN NUT,1/4-20 SS
T1
1
2 100097 SCREW,TRUSS HEAD,10-32 x 1/2 SS
T2
3 100100 SCREW,ROUND HEAD,8-32 x 1/4 SS
T2
4 100109 WELD-STUD,1/4-20 X 1/2 LG.SST 2
5 100113CAP,3/4" NPT SS
T1
6 100154 HEX PLAIN NUT,5/16-18 SST 6
7 100734 HEX HEAD,1/4-20 X 1/2 SS
T2
8 100736 HEX HEAD,1/4-20 X 3/4 SS
T2
9 100739 HEX HEAD,5/16-18 X 3/4 SS
T2
10 100740 HEX HEAD,5/16-18 X 1 SS
T4
11 102376 WASHER,FLAT,5/16x3/4x.06 SS
T4
12 102392 BUSHING,REDUCING,3/4"NPTx1/2"NPT,BRAS
S1
13 102438 ELBOW,STREET,1/2"NPT X 90, BRAS
S1
14 102505 PLUG,3/4"NPT SQ.HEAD,BRAS
S1
15 106013 WASHER,LOCK,5/16 SPLIT,SS
T6
16 106026 WASHER,FLAT,1/4x5/8x.06 SS
T2
17 106482 WASHER,LOCK,1/4 SPLIT,SS
T1
4
18 107967 HEX GRIP NUT,1/4-20 SST W/NYLO
N6
19 108576 BOOSTER HEATER COVE
R1
20 109069 THERMOSTAT WITH CAPILLARY 1
21 109682 THERMOSTAT COVER BO
X1
22 109925 FITTING, COMP 5/8 OD X 1/2 MPT BRAS
S1
23 109985 O-RING,BOOSTER HEATER 3
24 110561 THERMOSTAT WITH CAPILLARY 1
25 206668 ANGLE,ELECTRIC BOOSTER SUPPORT EUCC
W2
--- 206689 ANGLE,ELECTRIC BOOSTER SUPPORT EUC
C2
26 206669 ANGLE,ELECTRIC BOOSTER SUPPORT 1
27 314102 BOX,DUAL THERMOSTAT 1
28 328254 BRACKET,BOOSTER SUPPORT,W/HOL
E1
29 330571 BRACKET,PIPING SUPPORT,ELECTRIC BOOSTE
R1
30 414331 TANK. BOOSTER WELDMEN
T1
31 601833 SEE PAGE 102-103 FOR PIPING ASSY BREAKDOWN 1
32 601931 SEE PAGE 104-105 FOR PIPING ASSY BREAKDOWN 1
