CHANGHE FREEDOM SERVICE MANUAL ENGINE COOLING SYSTEM
4. WATER PUMP BELT
A. REMOVAL
1）Disconnect negative cable at battery.
2）Remove air cleaner assembly.
3) Loosen drive belt adjusting bolt and generator pivot
bolts. When servicing car equipped with A/C, remove
compressor drive belt before removing water pump belt.
4）Slacken belt by displacing generator and then remove
it.
B. INSTALLATION
1) Install belt to water pump pulley, crankshaft pulley
and generator pulley
When servicing car equipped with A/C, install
compressor drive belt, too.
2）Adjust belt tension.
For Adjustment of compressor drive belt tension, refer to
SECTION 2 of this manual.
3) Tighten water pump belt adjusting bolt and pivot bolts.
4)
Connect negative cable at battery.
efer to WATER
PUM
5. RADIATOR
ect negative cable at battery.
drain plug of
radia
isconnect coupler of cooling fan motor.
hose.
ped) and radiator bolts.
radiator.
B. IN
r for leakage or damage. Straighten bent fins, if any.
C. C
area of radiator cores.
D. IN
l procedures.
NOT
fill cooling system with proper coolant referring to COOLANT item of MAINTENANCE.
C. INSPECTION AND ADJUSTMENT
For this inspection or adjustment, r
P BELT TENSION.
A. REMOVAL
1）Disconn
2）Drain cooling system by loosening
tor.
3）D
4）Remove front bumper (see Section 9).
5）Remove air cleaner case and air intake
6）Remove A/C condenser mounting bolt (if equip
7）Disconnect radiator inlet and outlet hoses and reservoir tank hose from
8）Remove radiator with cooling fan motor.
SPECTION
Check radiato
LEANING
Clean frontal
STALLATION
Reverse remova
E：
z Re
zAfter installation, check each joint for leakage.
99
