CHANGHE FREEDOM SERVICE MANUAL BRAKES
256
NOT
z Be sure to inst ll brake flexible hose
E-ring into hose groove.
z Upon completion of installation, check
each joint for fluid leakage with brake pedal
depressed.
sing Proportioning Valve）
SPECTION & ADJUSTMENT
inspection and
adju
Full tank is filled with fuel fully.
ehicle is free from any other load.
4） If it isn't adjust it to specification by
lt (a) tightening positions as shown in
left f
ICE:
a
LSPV（Load Sen
IN
Confirm the following before
stment：
z
z Vehicle is equipped with spare tire, tool,
jack and jack handle.
z V
With vehicle in below conditions：
1） Place it on level floor.
2） Push up LSPV level with finger till stops
and measure length of coil spring（“L” in figure） as
it is pulled.
3） Spring length “L” should be the value
specified below: L=179mm.
changing bo
igure. After adjustment tighten nut to specified
torque.
Tightening Torque：23N·m
CAUTION：
z LSPV assembly must not be
disassembled. Replace with new one If found
defective.
To Next Page
