CHANGHE FREEDOM SERVICE MANUAL GEAR SHIFTING CONTROL
G
ENERAL DESCRIPTION
The gear shifting control system consists of following main parts. The gear shift control lever is
connected with the gear shift shaft and select shaft levers on the transmission case by means of two
cables (gear shift cable and select cable).
1. Gear shift control lever
2. Gear select arm
3. Control guide
4. Bush
5. Bush
6. Select arm return spring
7. Gear shift shaft lever
8. O-ring
9. Lever case pin
10. Shift lever hold No.1 spring
11. Lever hold washer
12. Reverse check spring
13. Reverse check ball
14. Gear shift lever
15. Reverse shift limit dog
16. Shift lever hold No.2 spring
17. Reverse gear shift spacer
162
