Check Point 4000 - Attaching the Rail Plates

Rack Mounting
Check Point 4000 Appliances Getting Started Guide | 23
Attaching the Rail Plates
Attach the rail plates to the appliance rails to connect the appliance to the rear vertical rails of
the rack.
Item
Description
1
Appliance rail
2
Rail plate
Note - The appliance rail screws have 8 mm heads.
To attach the rail plates:
1. Attach a rail plate to an appliance rail using two appliance rail screws.
