Key
Item Description
4
PWR+12VDC Connects to the power supply unit's cable.
Note - The power unit cable must be
securely screwed in to the appliance.
5
Reboot button Lets you forcibly reboot the appliance. The
button is recessed into the appliance
chassis to prevent accidental reboot. The
appliance reboots after you press the
button.
6
Console port RJ45 or Mini USB Serial connection
configured to 115200 bps by default. You
can also use this port to connect an analog
modem. Note - When both the RJ45 and
Mini USB cables are connected, the Mini
USB takes precedence.
7
DMZ and WAN
ports
Built in Ethernet ports.
8
Ground (Earth) Functional grounding.
9
LAN1 - LAN6
ports
Built in Ethernet ports.
