CHINT NVF5 Series User Manual

NVF5 Series User Manual Appendix B Parameter list
Code
Name
Setting Range
Default
Change
Starting frequency
F1.07
DC braking
wait time
（0.0 ～ 100.0）s
0.0s
○
F1.08
DC braking
current
（ 0.0 ～ 100.0 ） % （ Rated
Current）
0.0%
○
F1.09
DC braking time
（0.00 ～ 100.0）s
0.0s
○
F1.10
Forward/Reverse
Deadband Time
（0.0 ～ 300.0）s
0.0s
○
F1.11
Forward/Reverse
Switch Mode
0 ：
Operating frequency lower
limit(F0.09) switching
1 ：
Starting frequency(F1.01)
switching
0
○
F1.12
Accel. / Decel. Mode
Selection
0：Ramp Accel./Decel.
1：S curve Accel./Decel. 1
2：S curve Accel./Decel. 2
0
◎
F1.13
S-curve Scale of
Starting Time
（0.0 ～ 100.0）%
30.0%
◎
F1.14
S-curve Scale of
Stopping Time
（0.0 ～ 100.0）%
30.0%
◎
F2 Motor Parameter Group
F2.00 Motor Type
0：AC Induction Motor
1：Reserve
2：Reserve
0
◎
F2.01 Motor NP Power
（0.1 ～ 1000.0）kW
Depend on
motor type
◎
F2.02 Motor NP Voltage
0V ～ Inverter Rated Voltage
Depend on
motor type
◎
F2.03 Motor NP Current
（0.01～ 1000.00）A
Depend on
motor type
◎
F2.04 Motor NP Frequency
0.01Hz ～
Max. Output
Frequency F0.07
Depend on
motor type
◎
F2.05 Motor Poles
2 ～ 24
Depend on
motor type
◎
F2.06 Motor NP RPM
（0 ～ 60000）rpm
1430
◎
F2.07
Motor Stator
Impedance
（0.001 ～ 65.535）Ω（Inverter
Power <= 55kW）
（0.0001 ～ 6.5535）Ω（Inverter
Power > 55kW）
Depend on
motor type
◎
F2.08 Motor Rotor Resistor
（0.001 ～ 65.535）Ω（Inverter
Power <= 55kW）
（0.0001 ～ 6.5535）Ω（Inverter
Power > 55kW）
Depend on
motor type
◎
F2.09
Motor Leakage
Inductance
（0.01 ～ 655.35）mH（Inverter
Power <= 55kW）
Depend on
motor type
◎
- 115 -
