CHINT NVF5 Series User Manual

NVF5 Series User Manual Chapter 6 Parameter Function Description
Code Name Default Setting Range Description
F5.00 HDI Input Type Selection 0
0 ～ 1
0: HDI-High
Speed
Pulse Input
1：Common
DI（Same as
DI1～DI4）
F5.15
HDI Min. Input Pulse
0.0 KHz 0.0 KHz ～ F5.17
100.0% is
the Scale
Percentage
of F0.07-
Max. Output
Frequency
F5.16
HDI Min. Input Pulse
Setting
0.0% （-100.0～+100.0）%
F5.17
HDI Max. Input Pulse
100.0
KHz
F5.15 ～ 100.0KHz
F5.18
HDI Max. Input Pulse
Setting
100.0% （-100.0～+100.0）%
6.2.5 Preset Speed Main Frequency Setting
NVF5 can realize 15 preset frequency at most，assigns 4 digital inputs used to select
as frequency reference.Also can be selected less than 4 DI to configure preset speed，For
missing bits, state 0 is calculated.
When the main frequency reference is preset speed, the function selection of DI
terminal should be set to the value of 24-27, that is, the input terminal of preset speed
should be specified.The Multi-Preset Frequency can be set in parameter group FA，see
below parameter setting：
Code Name Default
Setting
Range
Description
F5.01
DI1 Function
Selection
1
0 ～ 63
24 ：
Preset Speed
Terminal 1
25 ：
Preset Speed
Terminal 2
26 ：
Preset Speed
Terminal 3
27 ：
Preset Speed
Terminal 4
F5.02
DI2 Function
Selection
2
F5.03
DI3 Function
Selection
9
F5.04
DI4 Function
Selection
12
F5.05
HDI Function
Selection
0
The scale of preset speed is the percentage of Max. frequency F0.07. The positive
and negative parameters determine the direction of operation. If the value is negative, it
means the inverter runs in the opposite direction.
Assigns 4 digital inputs as preset frequency input channel - K1～K4，and compose 4
binary digits：Among them, 1 means effective, and 0 means ineffective.
The state can be combined into 15 states. These 15 states correspond to 15 setting
values.See below figure:
- 47 -
