Chison ECO 3 EXPERT - B Image Adjustment

ECO 3 EXPERT Ultrasound Diagnostic System
Page 36 / 191
4.3.6 Dist
Press this key to enter into distance measurement.
4.3.7 Trace
Press this key to enter into trace measurement, and press [UPDATE] to change between trace
and ellipse.
4.3.8 Calc
Press this key to enter into measurement software package.
4.3.9 MENU
Press MENU-knob for second time to select the item and adjust the parameters. Press
MENU-knob for third time to exit from current item. Rotate the MENU- knob to select the item.
4.3.10 Trackball
Trackball is the main operation tool on screen. Position calipers in measurement, the function of
the trackball is different under diverse working status.
4.4 The key of Image Mode
4.4.1 B
Display B mode.
4.4.2 2B
Press this key to enter into 2B mode.
4.4.3 4B
