Chison ECO 3 EXPERT - Small Parts Measurement; B Mode Vessel Measurement

ECO 3 EXPERT Ultrasound Diagnostic System
Page 77 / 191
Meas.
Menu
Submenu
Unit
Meas. Method
Comment
UT_W
cm
Refer to distance Meas.
UT_H
cm
Refer to distance Meas.
Cervix Vol.
ml
Refer to distance Meas.
Formula: V＝(π/6)×L×H×W
L: Cervix _L
H: Cervix _H
W: Cervix _W
ENDO
cm
Refer to distance Meas.
Ovary
Vol.(L/R)
ml
Refer to distance Meas.
Formula: V＝(π/6)×L×H×W
L: OV _L
H: OV _H
W: OV _W
FOllicle(L/R)
Follicle width
cm
Refer to distance Meas.
Follicle height
cm
Refer to distance Meas.
Follicle Volume
ml
Formula of 2distance V ＝
（π/6）×A×B
2
Formula of 3distance V ＝
（π/6）×L×H×W
2distance
A: the longer
distance
B: the shorter
distance
3distance
L: follicle length
H: follicle height
W: follicle width
6.9 Small Parts Measurement
Freeze the required image under Small parts examination, then press [Calc] to enter into small
parts measurement status.
Meas.
Menu
Submenu
Unit
Meas. Method/
Meas. Formula
Comment
Distance
cm
Refer to distance
Meas.
Thyroid(L/R)
Volume
ml
Refer to distance
Meas.
Formula: V ＝
(π/6)×L×H×W
L: Thyroid_L
H: Thyroid_H
W: Thyroid_W
Angle
Angle1
Angle2
deg
Refer to distance
Meas.
Angle Range:0°～180°
Ratio
Distance1
Distance2
cm
Refer to distance
Meas.
Formula: R=D1/D2
D1: First Distance
D2: Second Distance
6.10 B Mode Vessel Measurement
Refer to normal measurement in B mode.
