ECO 3 EXPERT Ultrasound Diagnostic System
Page 56 / 191
2. Select the body mark that you need.
3. Move trackball after adding the body mark image and then adjust the position of probe. Rotate
[MENU] or [ANGLE] knob can adjust the probe direction. Press Enter- key to confirm when
adjustment was finished.
4. Move the Trackball to change the position of the body mark;
5. If you want to exit from the body mark function, press again;
6. Press [EXIT] to exit body status and the body mark is fastened to the screen.
7. Press [DEL] to delete body marks.
5.12 Set the Direction of Arrow
Operation:
1. Press to display arrow;
2. Press [Change] button to select cursor type: arrow or cross. And change the size of the cursor.
3. Adjust the position of probe. Rotate [MENU] or [ANGLE] knob can adjust the probe direction.
4. Press [ENTER] to confirm when adjustment was finished.
5. Press [EXIT] to exit the arrow settings.
6. Press [DEL] to clear the arrows has inputted.
5.13 Image and Cine Disposition
5.13.1 The Principle of Cine Storage
In real image status, the image can be stored in the movie memory in chronological order,
maximum frames can be set. The maximum number of frames of the film storage can be set,
please refer to pre-set chapter.
If the movie memory is full, the recent frame saved into memory, the previous frame removed from
memory.
