Chison ECO 3 EXPERT - M;B;M Mode Measurements

ECO 3 EXPERT Ultrasound Diagnostic System
Page 70 / 191
Meas.
Menu
Submenu
Unit
Meas. Method/
Meas. Formula
Comment
Volume
(1Ellipse)
ml
Refer to ellipse
meas.
Formula: V ＝
(π/6)×A×B2
A: Long Axis
B: Short Axis
Volume
(2 Distance)
ml
Refer to
distance Meas.
Formula: V ＝
(π/6)×D1×D22
D1: the longer distance
D2: the shorter distance
Volume
(3 Distance)
ml
Refer to
distance Meas.
Formula: V ＝
(π/6)×D1×D2×D
3
D1, D2, D3: Distance
Volume(1
Dis1Ellip)
ml
Refer to
distance and
ellipse Meas.
Formula: V ＝
(π/6)×A×B×M
A: Long Axis
B: Short Axis
M: Distance
Ratio
Ratio(distance)
Refer to
distance Meas.
Formula:
R=D1/D2
D1: First Distance
D2: Second Distance
Ratio(area)
Refer to ellipse
Meas.
Formula:
R=A1/A2
A1: First Area
A2: Second Area
deg
Refer to
distance Meas.
Angle Range:0°~ 180°
Refer to
histogram
Refer to
Cross-section
6.5 ABD Measurement
Choose ABD exam mode. Freeze the required image, and then Press [Calc] to enter into ABD
measurement status. Or press [Change] to choose the ABD measurement.
Meas.
Menu
Submenu
Unit
Meas. Method/
Meas. Formula
Comment
Distance
cm
Refer to
distance Meas.
