5.6.10 Angle
Change the angle of sampling line of sampling gate in PW mode.
Press [ANGLE/ZOOM] confirm the light of ANGLE on, the sampling line rotates with the direction.
5.6.11 ANGLE/ZOOM
Press [ANGLE/ZOOM] knob until the indicator of [ANGLE] is lit, and the angle of sample gate will
rotate with the rotation direction.
Press [ANGLE/ZOOM] knob to confirm the ZOOM button is lit, and it will appear the zoom box,
rotate the knob to select the zoom steps.
5.6.12 INVERT
B mode image and B/M mode image can be reversed horizontally and vertically.
Press the key, the displayed image is reversed in the right-left horizontal direction.
Press the key, the displayed image is reversed in the up-down vertical direction.
The horizontal flip status indicators of the upper-left corner of the image window have the following
meanings:
The meaning of the symbol “ ” indicating the probe initiative scanning position “ ” situated in the
left indicates that the first scanning line in the left of the screen is corresponding to the initiative
scanning position of the probe,
“ ” situated in the right indicates that the first scanning line in the right of the screen is
corresponding to the initiative scanning position of the probe.
5.6.13 THI
Turn ON/OFF THI.
5.6.14 AIO
Press this key to optimize image.
5.7 B Image Menu Adjustment
Click [Change] key or [MENU] knob to display the menu.
