ECO 3 EXPERT Ultrasound Diagnostic System
Page 66 / 191
4. Move the cursor to the end-point, press [ENTER] again to complete the measurement.
5. After the measurement, the result will display in the measurement results area.
6. Repeat the steps from 1 to 4 to start next “distance” measurement. Press [DEL] to delete all the
measurements.
NOTE:
Each group of measurement is limited, if the measurement results beyond, it will begin a new
group of measurement automatically.
6.2.2 Ellipse
Measurement steps:
1. Press the [Calc] button to enter into measurement. Update the [Ellipse] item in the menu; it will
display a segment “+”icon.
2. Move the “+”icon by cursor, Press [ENTER] to fix the point and the cursor can be moved to
form a round.
3. Press [UPDATE] can exchange the activated point and the fixed point.
4. Move the cursor to the end-point of the ellipse, press [ENTER] to fix the axis, at the same time,
the next axis be updated, and can change the size of the axis by the cursor.
5. Now press [UPDATE] can exit to the step 4.
6. After fixing the next axis, can press [ENTER] to complete the measurement.
7. After the measurement, the result will display in the measurement results area.
8. Repeat the steps from 1 to 6 to start next “ellipse” measurement. Press [DEL] to delete all the
measurements.
NOTE:
Each group of measurement is limited, if the measurement results beyond, it will begin a new
group of measurement automatically.
6.2.3 Trace
Measurement steps:
1. Press the [Calc] button to enter into measurement. Update the [Trace] item in the menu or
press the quick measure button [Trace]; it will display a segment “+”icon.
