Programmable AC Source 61501/61502/61503/61504 User’s Manual
5-2
Press
SHIFT, then  to change to next page for sequence programming.
SEQ: the number of sequence. All sequences must start by zero. The maximal number of
SEQ is 99.
DEGREE: the phase angle when the sequence starts.
Vs, Fs, DCs: the initial waveform when the sequence starts.
Ve, Fe, DCe: the final waveform when the sequence ends.
WAVE = A / B: to choose waveform (see 3.6.3).
TIME / CYCLE: the length of sequen
ce.
After setting sequences, press
PAGE/EXIT to exit to LIST mode page. Press SHIFT , then
ENTER to change to execution page. The LCD shows _TRIG_ON is under action, and *
STOP * is the triggering status at present. Press ENTER to trigger. Then LCD shows
status * RUNNING * and TRIG_OFF waiting for user to stop the LIST waveform output. The
LCD will shows * STOP * when the AC source executed all sequences and COUNT.
If the AC Source is in running status, press OUT/QUIT, the output will quit waveform to zero
voltage. Then, if press OUT/QUIT again, the AC source only out the waveform set in MAIN
PAGE. Users must press ENTER to trigger again. Or if in quit status, users can press
ENTER to output LIST waveform directly.
The programmed LIST mode waveform will shut down when press
PAGE/EXIT to exit LIST
execution page.
SEQ = 0 DEGREE = 0.0 [ LIST ]
Vs = 0.0 Fs = 60.00 DCs = 0.0
Ve = 0.0 Fe = 60.00 DCe = 0.0 S
WAVE = A TIME = 0.0 ms T
_TRIG_ON * STOP * [ LIST ]
V = 0.00 F = 0.00 I = 0.00 S
P
= 0.0 PF = 0.000 CF = 0.00 T
_TRIG_OFF * RUNNING * [ LIST ]
V = 0.00 F = 0.00 I = 0.00 S
P
= 0.0 PF = 0.000 CF = 0.00 T
