Programmable AC Source 61501/61502/61503/61504 User’s Manual
2-2
WARNING
To protect the operators, the wire connected to the GND terminal must
be connected to the earth ground. Under no circumstances shall this
AC source be operated without an adequate ground connection.
Installation of the power cord must be done by a professional and in accordance with local
electrical codes.
Figure 2-1 Input Connection
Figure 2-2 Input Terminal Cover
