Chroma 61503 - Names of Parts; Front Panel

General Information
1-3
Temperature Range
Operation
0 °C to 40 °C
Storage
-40 °C to 85 °C
Humidity 30 % to 90 %
Safety & EMC FCC 15J class A, CE
Remarks
*1: Maximum distortion is tested on output 125VAC (150V RANGE) and 250VAC
(300V RANGE) with maximum current to linear load.
*2: Load regulation is tested with sinewave and remote sense.
*3: Efficiency is tested on input voltage 110V.
1.4 Names of Parts
1.4.1 Front Panel
1
2
3 4 5
67
8
9
10
11
Figure 1-1 Front Panel
