Programmable AC Source 61501/61502/61503/61504 User’s Manual
1-2
Model 61501 61502 61503 61504
AC OUTPUT RATING
Max. power 500 VA 1K VA 1.5K VA 2K VA
Voltage
Range 150V / 300V / Auto
Accuracy 0.2%+0.2%F.S. 0.2%+0.2%F.S. 0.2%+0.2%F.S. 0.2%+0.2%F.S.
Resolution 0.1 V 0.1 V 0.1 V 0.1 V
Distortion
0.3% @50/60Hz
1% 15- 1K Hz
0.3% @50/60Hz
1% 15- 1K Hz
0.3% @50/60Hz
1% 15- 1K Hz
0.3% @50/60Hz
1% 15- 1K Hz
Line regulation 0.1% 0.1% 0.1% 0.1%
Load regulation 0.2% 0.2% 0.2% 0.2%
Temp. coefficient
0.02% per degree from 25°C
Maximum current
r.m.s. 4A / 2A 8A / 4A 12A / 6A 16A / 8A
peak 24A / 12A 48A / 24A 72A / 36A 96A / 48A
Frequency
Range DC, 15-1K Hz DC, 15-1K Hz DC, 15-1K Hz DC, 15-1K Hz
Accuracy 0.15% 0.15% 0.15% 0.15%
DC OUTPUT RATING
Power 250W 500W 750W 1K W
Voltage 212V / 424V 212V / 424V 212V / 424V 212V / 424V
Current 2A / 1A 4A / 2A 6A / 3A 8A / 4A
OUTPUT IMPEDANCE
Range
0.0Ω+200uH - 1.0Ω+1.0mH
HARMONICS & SYNTHESIS SIMULATION
Bandwidth 50Hz / 60Hz 40 order
INPUT RATING
Voltage range 90-250V 90-250V 90-250V 90-250V
Frequency range 47-63 Hz 47-63 Hz 47-63 Hz 47-63 Hz
Current 8A Max. 16A Max. 21A Max. 28A Max.
Power factor 0.97 Min. 0.98 Min. 0.98 Min. 0.98 Min.
MEASUREMENT
Voltage
Range 150V / 300V 150V / 300V 150V / 300V 150V / 300V
Accuracy 0.2%+0.2%F.S. 0.2%+0.2%F.S. 0.2%+0.2%F.S. 0.2%+0.2%F.S.
Resolution 0.1 V 0.1 V 0.1 V 0.1 V
Current
Range (peak) 24A 48A 72A 96A
Accuracy (r.m.s.) 0.4%+0.3%F.S. 0.4%+0.3%F.S. 0.4%+0.3%F.S. 0.4%+0.3%F.S.
Accuracy (peak) 0.4%+0.6%F.S. 0.4%+0.6%F.S. 0.4%+0.6%F.S. 0.4%+0.6%F.S.
Resolution 0.01 A 0.01 A 0.01 A 0.01 A
Power
Accuracy 0.4%+0.4% F.S. 0.4%+0.4% F.S. 0.4%+0.4% F.S. 0.4%+0.4% F.S.
Resolution 0.1 W 0.1 W 0.1 W 0.1 W
OTHERS
Efficiency 68 % 77 % 78 % 80 %
Size (H×W×D) 133.35 × 482.6 × 569.5 mm / 5.25 × 19 × 22.42 inch
Weight
20 kg / 44.05 lbs 20 kg / 44.05 lbs 20 kg / 44.05 lbs 20 kg / 44.05 lbs
Protection UVP, OCP, OPP, OTP, FAN
