Chroma 61503 - GPIB Address, RS-232 C; OUTPUT Functional List

Local Operation
3-15
3.6.5 GPIB Address, RS-232C
The AC source offers the mode of remote operation too. The user can set them on CONF
functional list (see 3.6). For detailed please refers to Chapter 7. Prior to remote operation
the user has to set the GPIB address 10 as below:
1. Move the cursor to the command ADDR = 30_
line of GPIB address.
2. Press
1 , 0 , ENTER to set address 10. ADDR = 10
Addressing space ranges from 1 to 30.
The AC source offers another remote operation through the RS-232C bus. Communication
protocol is set as follows:
To set parity=ODD, baud rate=19200.
1. Move the cursor to the command
line of PARITY. BAUD=9600 PARITY= NONE_
2. Turn RPG to select ODD, then
press
ENTER. BAUD=9600 PARITY=ODD_
3. The cursor moves automatically to
the setting position of “BAUD”. BAUD=19200 PARITY=ODD
Turn RPG to select "19200", then
press
ENTER.
The options of baud rate are 9600/19200. The options of parity are
EVEN/ODD/NONE.
3.7 OUTPUT Functional List
On CHOICE PAGE (see 3.4), press 3 then press ENTER, choose the OUTPUT functional
list.
PAGE CHOICE = 3_
1. SETUP 2.CONF 3.OUTPUT 4. MANUAL CALI
5.
LIST 6. PULSE 7. STEP 8. HAR 9. SYN
10. INTERHAR
