Programmable AC Source 61501/61502/61503/61504 User’s Manual
3-10
2. Turn RPG to change the option from
OFF to ON, then press
ENTER . DATALOCK = ON
1. The user must select OFF to unlock.
2. If users use FUNC, please be sure the voltage output settings
stored in the memory. Unexpected voltage output may damage
the UUT.
3.5.8 Is START, Is INTERVAL
Is is the surge peak current of AC source output shown in MAIN PAGE. Is measurement
starts at Is START after output voltage transition. The length of measurement time is Is
INTERVAL. The user can set both on SETUP functional list (see 3.5).
The procedures of setting Is START = 10 ms, Is INTERVAL = 200 ms, are described as
below:
1. Move the cursor to the command line Is START= 0.0_ ms
of “Is START = ”.
2. Press
1 , 0 then press ENTER to
change the value to “10.0”. Is START = 10.0 ms
3. The cursor moves to the command line
of “Is INTERVAL = ” automatically. Is INTERVAL = 50.0_ ms
4. Press
2 , 0 , 0 then press ENTER
to change the value to “200.0”. Is INTERVAL = 200.0_ ms
3.6 CONF Functional List
On CHOICE PAGE (see 3.4), press 2 then ENTER, choose the CONF functional list.
PAGE CHOICE = 2_
1. SETUP 2.CONF 3.OUTPUT 4. MANUAL CALI
5.
LIST 6. PULSE 7. STEP 8. HAR 9. SYN
10. INTERHAR
