TEST ACTION APPLICABILITY
5 Turn the ignition off.
Disconnect the A/C Clutch Relay from the PDC.
Disconnect the A/C Clutch harness connector.
Measure the resistance of the (C3)A/C Clutch Relay Output circuit between the PDC
and the A/C Clutch harness connector.
Is the resistance below 5.0 ohms?
All
Yes → Replace the A/C Clutch Relay.
Perform POWERTRAIN VERIFICATION TEST VER-2-NGC.
No → Repair the (C3) A/C Clutch Relay Output circuit for an open.
Perform POWERTRAIN VERIFICATION TEST VER-2-NGC.
298
DRIVEABILITY - NGC
*CHECKING THE A/C RELAY OUTPUT — Continued
