Chrysler Pacifica CS 2004 - Fuel Pump Relay; Manifold Tuning Valve Relay; Starter Motor Relay

FUEL PUMP RELAY
CAV CIRCUIT FUNCTION
30 INTERNAL FUSED B(+)
85 INTERNAL FUSED IGNITION SWITCH OUTPUT (RUN-START)
86 K31 20BR FUEL PUMP RELAY CONTROL
87 N1 16DB/OR FUEL PUMP RELAY OUTPUT
87A - -
MANIFOLD TUNING VALVE RELAY
CAV CIRCUIT FUNCTION
30 INTERNAL FUSED B(+)
85 INTERNAL GROUND
86 K36 20DB/YL MTV CONTROL
87 K136 18BR MANIFOLD TUNING VALVE RELAY OUTPUT
87A - -
STARTER MOTOR RELAY
CAV CIRCUIT FUNCTION
30 INTERNAL FUSED B(+)
85 T751 20YL IGNITION SWITCH OUTPUT (START)
86 T752 20DG/OR STARTER RELAY CONTROL
87 T750 12YL/GY STARTER MOTOR RELAY OUTPUT
87A - -
C
O
N
N
E
C
T
O
R
P
I
N
O
U
T
S
346
CONNECTOR PINOUTS
