Symptom:
P0071-AMBIENT TEMP SENSOR PERFORMANCE
When Monitored and Set Condition:
P0071-AMBIENT TEMP SENSOR PERFORMANCE
When Monitored: Engine off time is greater than 480 minutes. Ambient temperature is
greater than -23°C(-10°F).
Set Condition: After a calibrated amount of cool down time, the PCM compares the ECT
Sensor, IAT Sensor and the Ambient Air Temperature Sensor values. If the Ambient Air
Temperature Sensor value is not within a calibrated temperature amount of the other two
temperature sensors an error is detected. Two Trip Fault.
POSSIBLE CAUSES
GOOD TRIP EQUAL TO ZERO
(K25) AAT SIGNAL CIRCUIT SHORTED TO BATTERY VOLTAGE
AMBIENT AIR TEMPERATURE SENSOR VOLTAGE BELOW 1.0 VOLT
(K25) AAT SIGNAL CIRCUIT OPEN
(K4) SENSOR GROUND CIRCUIT OPEN
(K25) AAT SIGNAL CIRCUIT SHORTED TO GROUND
(K25) AAT SIGNAL CIRCUIT SHORTED TO (K4) SENSOR GROUND
PCM LOW
PCM HIGH
TEST ACTION APPLICABILITY
1 Ignition on, engine not running.
With the DRBIIIt, read DTCs and record the related Freeze Frame data.
Is the Good Trip Counter displayed and equal to zero?
All
Yes → Go To 2
No → Refer to the INTERMITTENT CONDITION symptom in the
Driveability category.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
46
DRIVEABILITY - NGC
