Symptom:
P2008-SHORT RUNNER SOLENOID CIRCUIT
When Monitored and Set Condition:
P2008-SHORT RUNNER SOLENOID CIRCUIT
When Monitored: The Engine running. ASD Relay is energized.
Set Condition: The PCM senses the SRV is not at the desired state. One Trip Fault.
POSSIBLE CAUSES
GOOD TRIP EQUAL TO ZERO
SHORT RUNNER VALVE SOLENOID OPERATION
ASD RELAY OUTPUT CIRCUIT
SRV CONTROL CIRCUIT SHORTED TO ASD RELAY OUTPUT CIRCUIT
SRV CONTROL CIRCUIT SHORTED TO GROUND
SRV CONTROL CIRCUIT OPEN
PCM
TEST ACTION APPLICABILITY
1 Ignition on, engine not running.
With the DRBIIIt, read DTCs and record the related Freeze Frame data.
Is the Good Trip displayed and equal to zero?
All
Yes → Go To 2
No → Refer to the INTERMITTENT CONDITION symptom in the
Driveability category.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
2 Turn the ignition off.
Disconnect the Short Runner Valve Solenoid harness connector.
Turn the ignition on.
Using a 12-volt test light, connect one end to the ASD Relay Output circuit and the
other end to the SRV Solenoid Control circuit.
With the DRBIIIt, actuate the SRV Solenoid.
Does the 12-volt test light flash on and off.
All
No → Go To 3
Yes → Replace the Short Runner Valve Solenoid.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
269
DRIVEABILITY - NGC
