TEST ACTION APPLICABILITY
3 Turn the ignition off.
Disconnect the SRV Solenoid harness connector.
Turn the ignition on.
Using a 12-volt test light connected to ground, check the ASD Relay Output circuit.
With the DRBIIIt, actuate the SRV Solenoid.
Does the 12-volt test light illuminate?
All
Yes → Go To 4
No → Repair the ASD Relay circuit.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
4 Turn the ignition off.
Disconnect the PCM harness connector.
Disconnect the SRV Solenoid harness connector.
Measure the resistance between the SRV Control circuit and ASD Relay Output
circuit in the SRV Solenoid connector.
Is the resistance below 5.0 ohms?
All
Yes → Repair the SRV Control circuit short to the ASD Relay Output
circuit.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
No → Go To 5
5 Turn the ignition off.
Disconnect the PCM harness connector.
Disconnect the SRV Solenoid harness connector.
Measure the resistance between ground and the SRV Control circuit at the SRV
Solenoid harness connector.
Is the resistance below 100 ohms?
All
Yes → Repair the short to ground in the SRV Control circuirt.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
No → Go To 6
6 Turn the ignition off.
Disconnect the PCM harness connector.
Disconnect the SRV Solenoid harness connector.
CAUTION: DO NOT PROBE THE PCM HARNESS CONNECTORS. PROBING
THE PCM HARNESS CONNECTORS WILL DAMAGE THE PCM TERMI-
NALS RESULTING IN POOR TERMINAL TO PIN CONNECTION. INSTALL
MILLER SPECIAL TOOL #8815 TO PERFORM DIAGNOSIS.
Measure the resistance of the SRV Control circuit from the SRV Solenoid harness
connector to the appropriate terminal of special tool #8815.
Is the resistance below 5.0 ohms?
All
Yes → Go To 7
No → Repair the open in the SRV Control circuit.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
7 NOTE: Before continuing, check the PCM harness connector terminals for
corrosion, damage, or terminal push out. Repair as necessary.
If there are no possible causes remaining, view repair.
All
Repair
Replace and program the Powertrain Control Module Module in
accordance with the Service Information.
Perform POWERTRAIN VERIFICATION TEST VER-5-NGC.
270
DRIVEABILITY - NGC
P2008-SHORT RUNNER SOLENOID CIRCUIT — Continued
