Chrysler Pacifica CS 2004 - Manifold Tuning Valve Solenoid - Dk. Gray 2 Way; Natural Vacuum Leak Detection Assembly - Black 3 Way; Oxygen Sensor-1;1 Upstream - Black 4 Way; Oxygen Sensor-1;2 Downstream - White 4 Way

MANIFOLD TUNING VALVE SOLENOID - DK. GRAY 2 WAY
CAV CIRCUIT FUNCTION
1 Z110 20BK/LG GROUND
2 K136 18BR MANIFOLD TUNING VALVE RELAY OUTPUT
NATURAL VACUUM LEAK DETECTION ASSEMBLY - BLACK 3 WAY
CAV CIRCUIT FUNCTION
1 Z166 18BK/WT GROUND
2 K107 20VT/WT NVLD SWITCH SIGNAL
3 K106 20VT/LB NVLD SOL CONTROL
OXYGEN SENSOR-1/1 UPSTREAM - BLACK 4 WAY
CAV CIRCUIT FUNCTION
1 Z42 18BK/LG GROUND
2 K99 18BR/TN O2 1/1 HEATER CONTROL
3 K902 18BR/DG O2 RETURN (UP)
4 K41 18DB/LB O2 1/1 SIGNAL
OXYGEN SENSOR-1/2 DOWNSTREAM - WHITE 4 WAY
CAV CIRCUIT FUNCTION
1 Z43 18BK/LB GROUND
2 K299 18BR/OR O2 1/2 HEATER CONTROL
3 K904 20DB/DG O2 RETURN (DOWN)
4 K141 20DB/YL O2 1/2 SIGNAL
C
O
N
N
E
C
T
O
R
P
I
N
O
U
T
S
351
CONNECTOR PINOUTS
