Symptom:
P0513-INVALID SKIM KEY
When Monitored and Set Condition:
P0513-INVALID SKIM KEY
When Monitored: Ignition on.
Set Condition: The PCM detects an invalid SKIM key.
POSSIBLE CAUSES
INCORRECT VIN IN PCM
INVALID SKIM KEY NOT PRESENT
NO COMMUNICATION WITH SKIM
NO VIN PROGRAMMED IN THE PCM
PCM
SKIM TROUBLE CODES SET
TEST ACTION APPLICABILITY
1 Turn the ignition on.
With the DRBIIIt, read the PCM DTCs.
Is the Good Trip Counter displayed and equal to zero?
All
Yes → Go To 2
No → Go To 7
2 With the DRBIIIt, attempt to communicate with the SKREEM.
Turn the ignition on.
Can the DRBIIIt communicate with the SKREEM?
All
Yes → Go To 3
No → Refer to the No Communication category.
Perform SKREEM VERIFICATION TEST - VER 1A.
3 Turn the ignition on.
With the DRBIIIt, check for SKREEM DTCs.
Are any DTCs present in the SKREEM?
All
Yes → Refer to SKREEM category for the related symptom(s).
Perform SKREEM VERIFICATION TEST - VER 1A.
No → Go To 4
4 Turn the ignition on.
With the DRBIIIt, display the VIN that is programmed in the PCM.
Has a VIN been programmed into the PCM?
All
Yes → Go To 5
No → Program the correct VIN into the PCM and retest.
Perform SKREEM VERIFICATION TEST - VER 1A.
203
DRIVEABILITY - NGC
