TEST ACTION APPLICABILITY
5 Turn the ignition on.
With the DRBIIIt, display the VIN that is programmed in the PCM.
Was the correct VIN programmed into the PCM?
All
Yes → Go To 6
No → Replace and program the Powertrain Control Module in accor-
dance with the Service Information.
Perform SKREEM VERIFICATION TEST - VER 1A.
6 Turn the ignition off.
Replace and program the SKREEM in accordance with the Service Information.
Turn the ignition on.
With the DRBIIIt, erase all SKREEM and PCM DTCs.
Attempt to start and idle the engine.
With the DRBIIIt, read the PCM DTCs.
Does the DRBIIIt display this code?
All
Yes → NOTE: Before continuing, check the PCM harness connector
termnals for corrosion, damage, or terminal push out. Repair as
necessary. Replace and program the Powertrain Control Module
in accordance with the Service Information.
Perform SKREEM VERIFICATION TEST - VER 1A.
No → Test Complete.
7 NOTE: You must obtain the SKREEM pin number.
NOTE: This DTC could have been set if the SKREEM harness connector was
disconnected, or if the SKREEM was replaced recently.
NOTE: All keys that the customer uses for this vehicle must be tested to
verify they are operating properly.
Turn the ignition on.
Verify the correct VIN is programmed into the PCM and SKREEM.
Turn the ignition off.
With the next customer key turn the ignition key on and crank the engine to start.
With the DRBIIIt, read the PCM DTCs. Look for P0513.
Is the Good Trip Counter for DTC P0513 displayed and equal to 0?
All
Yes → Replace the Ignition Key.
Perform SKREEM VERIFICATION TEST - VER 1A.
No → Test Complete.
NOTE: If this DTC cannot be reset, it could have been an actual theft
attempt.
204
DRIVEABILITY - NGC
P0513-INVALID SKIM KEY — Continued
