CIMLINE M1 - Page 43

43
Number Color Function
AWG Wire
Gauge
1 White Hose AC Voltage 16
2 Black Hose AC Voltage 16
3 Red/Black Stripe Burner Power 14
4 Red Battery (+) 12
5 White Burner Enable 16
6 Red Micro Panel Accessory Input 16
7 Green/Yellow Stripe Battery (-) 12
8 Green Generator Excite 16
9 Red Accessory Relay Output 16
10 Red Relay Panel Lug to Fuse 16
11 Red Fuse to Relay 16
12 Red Fuse to Burner Relay 16
13 Red Fuse to Terminal Strip 16
14 Red Terminal Strip to Hose Controller and Controller Strip 16
15 Yellow Hose Controller to Relay 16
16 Yellow/Black Stripe Hose Controller to Hose Light 16
17 Green/Yellow Stripe Ground (ALL GROUND SYMBOLS ON DRAWING) 16
18 Pink Material Controller to Burner Relay 16
19 White Sensor Wire Controller to Terminal Strip Sensor wire
20 Red Sensor Wire Controller to Terminal Strip Sensor wire
21 White Sensor Wire Terminal Strip to Hose Sensor wire
22 Red Sensor Wire Terminal Strip to Hose Sensor wire
23 Black Hose AC 16
24 Orange Fuse to Hose Accessory 16
25 Orange Hose Switch to Low Flow Switch 16
26 White Hose AC 16
28 Red Manifold Switch to Rotary 16
29 Gray Oil Controller to Agitator Manifold 16
30 Purple Material Controller to Pump Manifold 16
31 Gray Oil Controller to Material Controller 16
32 Tan Manifold to Switch 16
33 Gray Manifold to Agitator Switch 16
34 Green Manifold to Rotary Switch #3 16
35 Purple Manifold to Pump Switch 16
38 Orange Manifold to Low Flow Switch 16
M-Series Control Panel Wiring Diagram
