M4 Dual Hose Diesel Engine Components
See the included engine manual for additional engine component diagrams and information.
# PART # DESCRIPTION # PART # DESCRIPTION
1 111838 Engine 12 111111 Air Filter
3 422167 Plate, Engine Mount RH 13 111337 Oil Filter
4 100126 Washer - Flat .38 15 130431 Generator
5 409037 Exhaust Weld 16 155266 Ignition Key
8 200543 Battery Box 28 111872 Radiator Hose
9 152047 Rubber Isolator 29 430111 Long Gen. Adjust Bracket
10 111108 LOFA Control Switch * 111457 Fuel Filter
11 150212 Battery 26/26R-50-Wet * Not Shown
1
5
4
9
3
10
16
11
8
13
28
12
29
15
