70
# PART # DESCRIPTION
# PART # DESCRIPTION
8 404341 Dipstick - Melter
41 100512 Muffler Clamp - 2 In.
9 152664 Anchor Shackle W/Pin
42 140330 Jack 5000 Lb.
29 429581 Pin - Engagement
43 130050 Switch - Breakaway
30 154308 Spring
44 111838 Engine Assembly
31 111861 Set Collar - .56
45 130166 Gauge - 0-160 PSI
32 409756 Cabinet Panel - LH
46 200543 Battery Box
33 120073 Pipe Plug - .50 Galv
47 150212 Battery - 26/26R-50 Wet
34 130130 Thermometer - 24 In.
48 424534 Plate - Burner Shield
35 172619 Diesel Tank - Black
49 120053 Pipe Elbow - 90° .75 Galv
36 404518 Heat Chamber Sub-Assembly
50 406164 Expansion Tank
37 152197 Burner - Diesel 105-110
51 120559 Pipe Bushing - 2.0 x .75 Galv.
38 409037 Exhaust Weld
52 120433 Pipe Union - 1.0
39 155976 Exhaust Tube Weld
53 409088 Return Box Weld
40 155143 1.88 ID Interlock Flex Tube
54 200526 Heated Hose Kit - Standard
46 47
48
52
49
49
50
51
8
42
41
40
39
38
37
36
35
9
43
44
45
30
29
53
31
32
33
34
M-Series Miscellaneous Components and Parts
