59
Update
Chapter 3
Changing Symbology Settings
3.6 CODE 93
You can only confi
gure the scanner to read this symbology
or not.
*Enable
Disable
3.7 CODE 128
You can only confi
gure the scanner to read this symbology
or not.
*Enable
Disable
68
70
