Chapter 4
Defining Output Format
Configure
Code
ID
for
Interleaved 25
Configure
Code
ID
for
Matrix 25
Configure
Code
ID
for
MSI
Configure
Code
ID
for
Plessey
Configure
Code
ID
for
Telepen
Configure
Code
ID
for
UPC-A
Configure
Code
ID
for
UPC-E
4.3.3 CLEAR CODE ID SETTINGS
Clear All Code ID
Settings
96
98
