CipherLab RS31

175
Appendix II
UPC-E Switch to enable UPC-E decoding. Enable
Addon 2 Decide whether to decode UPC-E with addon 2.
 Ignore Addon
 Auto-discriminate
Ignore addon
Addon 5 Decide whether to decode UPC-E with addon 5.
 Ignore Addon
 Auto-discriminate
Ignore addon
Preamble Decide whether to include the UPC-
E preamble System
Character (and Country Code) in the data being transmitted.
 No transmit: transmits none of the above
 Transmit System Character: transmits system number only

Transmit Sys. Character and Country Code: transmits system
number and country code
Transmit
System
Character
Convert to UPC-A The UPC-E barcode will be expanded into UPC-A format, and
the next
process will follow the settings configured for
UPC-A.
Disable
Transmit Check Digit Decide whether to include the UPC-
E1 check digit (the last
character in the barcode) in the data being transmitted.
Enable
UPC-E1 Disable
UPC-E1 Switch to enable UPC-E1 decoding. Disable
Addon 2 Decide whether to decode UPC-E1 with addon 2.
 Ignore Addon
 Auto-discriminate
Ignore addon
Addon 5 Decide whether to decode UPC-E1 with addon 5.
 Ignore Addon
 Auto-discriminate
Ignore addon
Preamble Decide whether to include the UPC-
E1 preamble System
Character (and Country Code) in the data being transmitted.
 No transmit: transmits none of the above
 Transmit System Character: transmits system number only

Transmit Sys. Character and Country Code: transmits system
number and country code
Transmit
System
Character
Convert to UPC-A The UPC-E1 barcode will be expanded into UPC-
A format,
and the next process will follow the settings configured for
UPC-A.
Disable
Transmit Check Digit Decide whether to include the UPC-E1 check digit
(the last
character in the barcode) in the data being transmitted.
Enable
Coupon Code
Coupon Code Switch to enable Coupon Code decoding. Disable
