4.2.- DISPLAY
The device has a LCD display with 3 lines, 4 digits each, to view the measured parameters and
tocongurethedevice.
Units
Conguration
0000
L1
0000
0000
V
L2
L3
Figure 10: Display CVM-C4�
4.3.- KEYBOARD FUNCTIONS
The CVM-C4 has 3 keys that allow you to browse through and program the device, Table 6 and
Table 7.
 Display screens:
Table 6: Keyboard function: Display screens�
Key Keystroke
Previous screen.
Next screen.
Long keystroke (> 3s):
Accessesthecongurationmenu
Congurationscreens:
Table 7: Keyboard function: Conguration screens.
Key Keystroke
Browses through the different menu screens.
Browses through the different options.
Browses through the different menu screens.
Browses through the different options.
Skipstothenextcongurationmenu.
Changes the digit's value.
Long keystroke (> 3s):
Enablesthevalue'sconguration
Validatesthecongurationparameter
