8�- TECHNICAL FEATURES
AC Power supply
(4)
Rated voltage
80... 270 V ~
Frequency 50 / 60 Hz
Consumption 6... 18 VA
Installation category CAT III 300V
DC Power supply
(4)
Rated voltage 80... 270 V 18... 36 V
Consumption 1.5 ...1.8 W 1,8... 2.2 W
Installation category CAT III 300V
(4)
Depending on model:
CVM-C4
Model
Power supply
80��� 270 V ~ 80��� 270 V 18��� 36 V
M52706
 
-
M527060030000
- -

Voltage measurement circuit
Rated voltage (Un)
3 x 230 V / 400 V ~ ± 20%
Frequency measuring margin 45... 65 Hz
Overvoltage 1.2 Un continuous, 2 Un Instantaneous (1 min)
Consumption < 0.2 VA (per phase)
Impedance >1.7MΩ
Installation category Cat III 300V
Current measurement circuit
Rated current (In) 1 A / 5 A ~
Frequency measuring margin 45... 65 Hz
Overcurrent 1.2 In continuous, 10 In Instantaneous (5s)
Consumption < 0.2 VA (per phase)
Impedance <20mΩ
Installation category Cat III 300V
Accuracy
Voltage measurement 0.2
Current measurement 0.2
Power measurement 0.5
Active and reactive energy measurement 0.5
Relay outputs
Quantity 2
Contact capacity (resistive) AC: 5A / 250 V~ , DC: 5A / 30 V
Maximum voltage open contacts 277 V~ / 30 V
Maximum current 5 A
Maximum switching capacity 1385 VA / 150 W
Electrical life (250 V~ / 5A) 1 x 10
5
