4�7�2�2� Measurement variables�
AlltheadressesofModbusmemoryareinHexadecimal�
ForthesevariablesisimplementedtheFunction 0x03and0x04�
Table 17: Modbus memory map ( Table 1)
Parameter Symbol Instantaneous Maximum Mínimum Units
L1Phase-Neutralvoltage V1 00-01 84-85 100-101 Vx10
L1Current A1 02-03 86-87 102-103 mA
L1ActivePower kW 1 04-05 88-89 104-105 W
L1ReactivePower kvar 1 06-07 8A-8B 106-107 var
L1InductiveReactivePower kvarL1 17C-17D 18E-18F 1A0-1A1 var
L1CapacitiveReactivePower kvarC1 182-183 194-195 1A6-1A7 var
L1ApparentPower kVAL1 188-189 19A-19B 1AC-1AD VA
L1PowerFactor PF1 08-09 8C-8D 108-109 x100
L2Phase-Neutralvoltage V2 0A-0B 8E-8F 10A-10B Vx10
L2Current A2 0C-0D 90-91 10C-10D mA
L2ActivePower kW 2 0E-0F 92-93 10E-10F W
L2ReactivePower kvar 2 10-11 94-95 110-111 var
L2InductiveReactivePower kvarL2 17E-17F 190-191 1A2-1A3 var
L2CapacitiveReactivePower kvarC2 184-185 196-197 1A8-1A9 var
L2ApparentPower kVAL2 18A-18B 19C-19D 1AE-1AF VA
L2PowerFactor PF1 12-13 96-97 112-113 x100
L3Phase-Neutralvoltage V3 14-15 98-99 114-115 Vx10
L3Current A3 16-17 9A-9B 116-117 mA
L3ActivePower kW 3 18-19 9C-9D 118-119 W
L3ReactivePower kvar 3 1A-1B 9E-9F 11A-11B var
L3InductiveReactivePower kvarL3 180-181 192-193 1A4-1A5 var
L3CapacitiveReactivePower kvarC3 186-187 198-199 1AA-1AB var
L3ApparentPower kVAL3 18C-18D 19E-19F 1B0-1B1 VA
L3PowerFactor PF3 1C-1D A0-A1 11C-11D x100
Three-phaseActivepower kW III 1E-1F A2-A3 11E-11F W
Three-phaseInductivePower kvarLIII 20-21 A4-A5 120-121 var
Three-phaseCapacitivePower kvarLIII 22-23 A6-A7 122-123 var
Three-phaseCosφ Cosφ III 24-25 A8-A9 124-125 x100
Three-phasePowerFactor PFIII 26-27 AA-AB 126-127 x100
Frequency Hz 28-29 AC-AD 128-129 Hzx10
L1-L2Voltage V12 2A-2B AE-AF 12A-12B Vx10
L2-L3Voltage V23 2C-2D B0-B1 12C-12D Vx10
L3-L1Voltage V31 2E-2F B2-B3 12E-12F Vx10
THDVoltageL1 %THDV1 30-31 B4-B5 130-131 %x10
THDVoltageL2 %THDV2 32-33 B6-B7 132-133 %x10
THDVoltageL3 %THDV3 34-35 B8-B9 134-135 %x10
THDCurrentL1 %THDI1 36-37 BA-BB 136-137 %x10
THDCurrentL2 %THDI2 38-39 BC-BD 138-139 %x10
THDCurrentL3 %THDI3 3A-3B BE-BF 13A-13B %x10
Three-phaseApparentPower kvaIII 42-43 C6-C7 142-143 VA
Maximumdemand Md(Pd) 44-45 C8-C9 - W/VA/mA
