Parameter Symbol Instantaneous Maximum Mínimum Units
Three-phasecurrent(average) I_AVG 46-47 CA-CB 146-147 mA
MaximumdemandI2 Md(Pd) 52-53 D6-D7 - mA
MaximumdemandI3 Md(Pd) 54-55 D8-D9 - mA
Phase-Phasevoltage(average) VF-AVG 56-57 DA-DB 156-157 Vx10
Phase-Neutralvoltage(average) VL-AVG 58-59 DC-DD 158-159 Vx10
4�7�2�3� Energy variables
AlltheadressesofModbusmemoryareinHexadecimal�
ForthesevariablesisimplementedtheFunction 0x03and0x04�
Table 18: Modbus memory map ( Table 2)�
Parameter Symbol Tari󰀨 1 Tari󰀨 2 Units
Activeenergy kWh III 3C-3D 6C-6D Wh
inductivereactiveenergy(kvarhL) kvarhLIII 3E-3F 6E-6F varh
capacitivereactiveenergy(kvarhC) kvarhCIII 40-41 70-71 varh
apparentenergy(kVAh) kVAhIII 5E-5F 72-73 kVAh
Generatedactiveenergy kWhIII(-) 60-61 74-75 Wh
Generatedinductivereactiveenergy kvarhLIII(-) 62-63 76-77 varh
Generatedcapacitivereactiveenergy kvarhCIII 64-65 78-79 varh
Generatedapparentenergy kVAhIII 66-67 7A-7B VAh
CO
2
emissions KgCO
2
68-69 7C-7D KgCO
2
x100000
GenerationCost $ 6A-6B 7E-7F $x100000
Hourspertari󰀨 Hours 80-81 82-83 seg
