----- Supply network analyzer CVMk and CVMk-ITF ------ Page Nº 43
11.2.3. CVMk-... COMMANDS WITH THE ENERGY + CLOCK MODULE
(*) negative energies only for the CVMk- 4C (four quadrants).
COM..
CONCEPT QUESTION ANSWER UNIT
RWH
(*)
Read active energy (positive,
negative - absolute value -)
$pp RWH ch
$pp 1 x 9 digits ch
$pp 2 x 9 digits ch
W.h
RLH
(*)
Read inductive energy
(positive, negative - absolute
value -
)
$pp RLH ch
$pp 1 x 9 digits ch
- For the CVMk-4C :
$pp 2 x 9 digits ch
varh.L
RCH
(*)
Read capacitive energy
(positive, negative - absolute
value)
$pp RCH ch
$pp 1 x 9 digits ch
- For the CVMk-4C :
$pp 2 x 9 digits ch
varh.C
RCE
Read initial value of the
positive energies: kW.h,
Kvarh.L and kvarh.C
$pp RCE ch
$pp 3 x 9 digits ch
W.h
(*)
RCe
Read initial value of the
negative energies: kW.h,
kvarh.L and kvarh.C
$pp RCe ch
$pp 3 x 9 digits ch
W.h
WCE
Write the three positive
energies (write initial value).
$pp 3 x 9 digits ch
$pp ACK ch
W.h
(*)
WCe
Write the absolute value of the
three negative energies
(write initial value).
$pp 3 x 9 digits ch
$pp ACK ch
W.h
RCL
Read date and time
dd/mm/yy hh:mm:ss
$pp RCL ch
$pp 17 characters ch
WCL
Write value for the clock
dd/mm/yyyy hh:mm:ss
$pp 19 charac. ch
( 10 + space +8 )
$pp ACK ch
RTS
Read SET-UP of three billing
period operation mode
(CVM/ RED-MAX module)
$pp RTS ch
$pp 3 digits ch
arg: 1d. tariff/ clock +1
Syncro/clock +1active
tariff type
